Technical
Specifications
|
| Size: |
3.5"
x 3.5" x 1.75" (Without Lens) |
| Weight: |
1.5
lbs. (Without Lens) |
| Enclosure: |
NEMA
rated extruded aluminum
|
| Mounting: |
Mounting
via 4 mounting/adjustment holes on front panel (Optional
mounting brackets available)
|
|
Lens
Mounting
|
Standard
C/CS Mounting
|
|
CCD:
|
2048
pixels
|
|
IR
Sensitive:
|
4520
IRD-IR Sensitive / 4520 Non-IR Sensitive
|
|
White
Balance:
|
Auto
or Fixed (Vision System Controlled)
|
|
Connection
:
|
Newton
10 pin Threaded Connector (Use with standard Newton Imager
Cables)
|
|
Power:
|
12
VDC @ 200mA
|
|
Weight:
|
15
Oz (450 grams)
|
|
Speed:
|
Up
to 5000 Lines per Second
|
|
Operating
Environment:
|
-5
Degrees C to +45 Degrees C
|
|
Minimum-Max
Storage Environment:
|
-20
Degrees C to +70 Degrees C
|
|
Adjustments:
|
Vision
System Controlled
|
|
Optional
Lens Iris Control:
|
Vision
System Controlled
|
|
Connections:
|
Newton
Labs Imager Cable
|
